Product Dimensions 17.75"h x 47.94"w x 22.88"d
The specially designed Range hood LED lighting emits a natural light to show the true colour and consistency of food. LEDs also conserve energy and are long lasting. The ClearView LED Range hood lighting system has been tested for the equivalent of 20 years' use.Read More
The temperature sensor is a safety device that constantly monitors the temperature when the hood fan is switched on. If a certain temperature is exceeded the hood fan automatically switches to the intensive setting. This avoids unnecessary energy consumption. The temperature sensor provides added peace of mind.
Operating the fan power and LED lighting on the hood fan is intuitive and effortless with rotary controls.
Located behind the grease filters is the Miele CleanCover: Instead of sharp metal edges and electrical components you will find only a sealed, smooth surface. It is particularly easy to clean and protects you from coming in contact with cables and motor components. Miele attention to detail - for your convenience and safety.
Customized kitchen design - fully integrated 45 1/2 (1155) in (mm)
Perfect illumination - LED ClearView lighting
Dishwasher-proof - 4 high-quality stainless steel grease filters
LED ClearView lighting. Powerful lighting with minimal energy consumption. Eco-friendly and very durable: with up to 4 x 2 W, they provide the cooktop with uniform, warm downlighting.
General Specs | |
| Width (in.) | 47.94 |
| Height (in.) | 17.75 |
| Duct Size (in.) | 9.88" |
| Depth (in.) | 22.88 |
| Color | Stainless Steel |
| MPN | 9753510 |
| Appliance Fit Width (cm.) | 122 |
| Color/Finish Name | Stainless Steel |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Range Hood Type | Insert |
| ADA Compliant | No |
| ENERGY STAR Certified | No |
| Outdoor Approved | No |
| Appliance Fit Width (in.) | 48 |
| Product Weight (lbs.) | 56 |
| Smart Compatible | No |
| Bulb Type | LED |
| Grease Filter Type | Stainless Steel |
| Filter Indicator Light | No |
| Vent Location | Top |
| Ventilation Direction | Vertical |
| Width (cm) | 121.77 |
| Depth (cm.) | 58.12 |
| Product Weight (kg) | 25.4 |
| Voltage | 120 |
| Amp | 15 |
| Range Hood Features | Light |
| Ventilation Type | Ducted |
Construction Type | |
| Extractor unit | Yes |
Accessories Required | |
| Fan | Yes |
Operating Models | |
| External operation | Yes |
| Type of air guide | Vented system |
User Convenience | |
| Power levels (excluding booster level) | 3 |
| Temperature sensor | Yes |
Cleaning Convenience | |
| Easy-to-clean CleanCover hood liner | Yes |
| Dishwasher-safe grease collection channel | Yes |
Fan Options (Purchased Separately) | |
| DRIB XXL internal, fan power in m3/h | 1869 |
| DREB XXL external, fan power in m3/h | 1869 |
Technical Data | |
| Length of power cable in m | 2 (0.8) |
| Total rated load in kW | 0.812 |
Accessories Supplied | |
| Non-return flap | Yes |
